ITO for Optical Applications

October 22, 2020


ito optical coating blog

By Dan Fiore, Vice President of North American Coating Laboratories

One of the most unique evaporative coatings available today is Indium Tin Oxide or ITO as it is known. ITO belongs to a family of evaporative materials known as transparent conductive oxides. The family of transparent conductive oxides includes Indium Tin Oxide (ITO) as mentioned before, ITO is the industry standard for transparent conductive films as it is robust, has good sheet resistance range and respectable UV-Visible and Near IR transmission which allows for good flexibility with multiple applications. Other members of the transparent conductive oxide family are IZO (Indium Zinc Oxide), and AZO (Aluminum Zinc Oxide).

Optical manufacturers and display industry companies use ITO in a variety of applications including electromagnetic shielding, electromagnetic interference filters, radio frequency interference filters, display windows, LCD fabrication, touch panels, CRTs, HUDs and finally for electrostatic discharge (ESD). Any application that could benefit from placing an electrical charge across a clear surface could potentially use an ITO coating. This makes ITO very appealing for those in the defense and aerospace industries as their applications typically call for their displays and control systems to have their electromagnetic and radio frequencies shielded or made “stealth” from radar systems.

There are multiple ways ITO can be deposited through vacuum coating. Among them are electron beam deposition and various forms of sputter deposition including Ion Beam and Magnetron. The sputtering applications are capable of achieving 1-ohm sheet resistance as they can produce an extremely dense film. They are very high energy and are limited to crystalline and glass substrates which can endure high energy/heat deposition. Electron beam deposition is lower energy and therefore can be used for glass and crystalline materials along with polymers. The only limiting factor with electron beam deposition is the sheet resistance is limited to about 4 ohms per square sheet resistance.

Because ITO is a clear material it can be “stacked” into a film with other dielectric materials to create a conductive anti-reflective coating. Other methods can help make ITO more suitable for a high transmission application. One of the most popular methods of lowering the surface reflectance and increasing the light transmission of ITO is a process called “Index Matching”. Index matching is a process where ITO which is a high index material is deposited on to the substrate and is then layered with middle and lower index materials to reduce the overall index of the ITO base layer closer to that of air’s refractive index which is 1.0. The challenge when producing an index matched film is that many of the dielectric materials that are placed above the ITO base layer are electrically insulative, so there needs to be a predetermined section or landing on the substrate where exposed ITO will be left after index matching so that a direct connection can be made to the  conductive film.

When deposited correctly and masked properly ITO coatings can be highly effective in so many different applications. Because Indium is a rare more expensive metal other transparent conductive film processes have started to gain favor. Among the most popular is Carbon nanotubes (CNTs) which have attracted attention because of their materials properties, including a high elastic modulus, a high tensile strength, and a high conductivity. Other alternatives are nanowires or metal meshes which can be deposited on rigid substrates and conduct a good electrical charge.
